52.10.060.2F

2刃深沟平刀

公差	d=h5
D≤3	0，-0.015
3<D<20	0，-0.02

刀具尺寸

涂层种类	开槽	侧铣	面铣	刃数	螺旋角	适合材料硬度
CrAL				2	30°	HRC≤52

切割材料
非常合适
合适

碳素钢

合金钢

调制钢

铸铁

淬硬钢

不锈钢

钛合金

铝合金

铜

树脂

石墨

高温合金

≤52hrc

>52hrc

订货号	刃径（mm）	避空长（mm）	刃长（mm）	避空径（mm）	柄径（mm）	全长（mm）
52.03.008.2F	0.3	0.8	0.3	0.28	4	45
52.03.010.2F		1				45
52.03.012.2F		1.2				45
52.03.015.2F		1.5				45
52.03.020.2F		2				45
52.03.025.2F		2.5				45
52.03.030.2F		3				45
52.04.010.2F	0.4	1	0.4	0.37	4	45
52.04.015.2F		1.5				45
52.04.020.2F		2				45
52.04.025.2F		2.5				45
52.04.030.2F		3				45
52.04.040.2F		4				45
52.04.050.2F		5				45
52.04.060.2F		6				45
52.05.015.2F	0.5	1.5	0.5	0.46	4	45
52.05.020.2F		2				45
52.05.030.2F		3				45
52.05.040.2F		4				45
52.05.060.2F		6				45
52.05.080.2F		8				45
52.05.100.2F		10				45
52.06.015.2F	0.6	1.5	0.6	0.56	4	45
52.06.020.2F		2				45
52.06.040.2F		4				45
52.06.060.2F		6				45
52.06.080.2F		8				45
52.06.100.2F		10				45
52.08.020.2F	0.8	2	0.8	0.76	4	45
52.08.030.2F		3				45
52.08.040.2F		4				45
52.08.060.2F		6				45
52.08.080.2F		8				45
52.08.100.2F		10				45
52.08.120.2F		12				45
52.10.040.2F	1	4	1.5	0.95	4	50
52.10.060.2F		6				50
52.10.080.2F		8				50
52.10.100.2F		10				50
52.10.120.2F		12				50
52.10.150.2F		15				50
52.15.060.2F	1.5	6	2.25	1.45	4	50
52.15.080.2F		8				50
52.15.100.2F		10				50
52.15.120.2F		12				50
52.15.150.2F		15				50
52.15.200.2F		20				60
52.15.250.2F		25				75
52.15.300.2F		30				75
52.20.080.2F	2	8	3	1.94	4	50
52.20.100.2F		10				50
52.20.120.2F		12				50
52.20.160.2F		16				50
52.20.200.2F		20				60
52.20.250.2F		25				75
52.20.300.2F		30				75
52.20.350.2F		35				75
52.20.400.2F		40				75
52.25.080.2F	2.5	8	3.75	2.4	4	50
52.25.100.2F		10				50
52.25.150.2F		15				50
52.25.200.2F		20				60
52.25.250.2F		25				75
52.25.300.2F		30				75
52.25.350.2F		35				75
52.25.400.2F		40				75
52.25.450.2F		45				100
52.25.500.2F		50				100
52.30.100.2F-6	3	10	4.5	2.85	6	50
52.30.150.2F-6		15				50
52.30.200.2F-6		20				60
52.30.250.2F-6		25				75
52.30.300.2F-6		30				75
52.30.350.2F-6		35				75
52.30.400.2F-6		40				75
52.30.450.2F-6		45				100
52.30.500.2F-6		50				100
52.30.550.2F-6		55				100
52.30.600.2F-6		60				100
52.40.160.2F-6	4	16	6	3.8	6	60
52.40.200.2F-6		20				60
52.40.250.2F-6		25				75
52.40.300.2F-6		30				75
52.40.400.2F-6		40				75
52.40.500.2F-6		50				100
52.40.600.2F-6		60				100
52.50.160.2F-6	5	16	7.5	4.8	6	60
52.50.200.2F-6		20				60
52.50.250.2F-6		25				75
52.50.300.2F-6		30				75
52.50.400.2F-6		40				75
52.50.500.2F-6		50				100
52.50.600.2F-6		60				100
